The Lumis is a versatile polyaxial top loading pedicle screw system specially designed for Minimally Invasive Surgery. Streamlined and powerful, the Lumis is fully compatible with the Flex +2 rods to perform a dynamic or hybrid construct through a percutaneous approach.
KEY FEATURES & BENEFITS
0%
Dynamic stabilization even in MIS
- Fully compatible with the Flex +2 rods
- Patented dynamic rod to be percutaneously implantable
Percutaneous screw placement
- Easy to use and secured Ø 14.5mm extension
- +/- 30° polyaxiality
- Low profile implants
Comprehensive range of implants
- Screw diameters from 5.5mm to 8.5mm in 1mm increments
- Length from 30 up to 60 mm in 5 mm increments
- 6mm diameter titanium alloy rods, from 30mm to 140mm in length
Ergonomic and time saving instrumentation
- Quick and easy extension loading
- Double lead thread for fast insertion
- Color coded screws for quick identification
- Two different solutions for rod introduction
- 2 types of persuaders (from 16 to 33mm of offset)
CE marking : YES
FDA clearance: YES
Lumis ® is a class IIb medical device, manufactured by SPINEVISION SAS – France. Lumis and SPINEVISION are registered trademarks of SPINEVISION or one of its subsidiaries.
See package insert for labeling information.
